High Speed 1600mm Carton Printing Slotting Machine Making Corrugated Box

High Speed 1600mm Carton Printing Slotting Machine Making Corrugated Box

Product Details:

Place of Origin: CHINA
Brand Name: AO DONG
Certification: CE ISO9001
Model Number: 1600-2600/custom

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 10000-500000
Delivery Time: 50
Payment Terms: T/T, D/P, L/C, D/A
Supply Ability: 8
Get Best Price Contact Now

Detail Information

Name: Corrugated Box Printing Machine Product Name: Corrugated Cardboard Printing Die Cutting Machine
Model: 1600-2600 Ce: Ok
Type: Carton Box Printing Machine Automatic Grade: Automatic,Semi-Automatic
Voltage: 220V/380V/440V After-sales Service Provided: Avaliable
High Light:

high speed carton printing slotting machine

,

1600mm carton printing slotting machine

,

corrugated carton box printing slotting machine

Product Description

High speed carton printing slotting machine for making corrugated carton box

Product Description

Machine performance:

1) The control panel is equipped with a man-machine interface PLC touch screen, which can control the paperboard feeding unit, printing unit, slotting unit, and die cutting unit,matched with auto stacker unit to collect carton sheet. It is easy to operate, fast, and high precision.

2) Each unit has PLC touch screen is assembled for easier operation and adjustment. Computer control can be Store 999 commonly used orders, change orders faster and more convenient to operate (operated by independent computer station).

3) All drive rollers are made of high-quality steel, hard chrome plated, and the surface is ground.

4) The transmission gear 50mm thick is made of high-quality steel grinding teeth.

5) The units of the whole machine are separated as a whole or individually; the bell continuously warns when walking to ensure the safety of the operator.

6) Automatic oil balancing device to keep the oil of each unit at the same level.

7) The wallboard thickness of the main frame is made of HT250 castings, with thickness of 50mm, and processed by a large-scale CNC Machining Center to ensure high strength and high precision.

8) Main electrical parts: Main motor adopts TECO brand,from Taiwan, the inverter adopts DELTA, and the contactor and button adopt Schneider or Simens brand.

Equipment composition:

1. Automatic feeding unit (vacuum suction lead egge feeding type )

2. Printing unit

3. Slotting unit

4. Auto stacker unit (optional for wasteboard vibration device)

Main technical parameters:

Model Unit LUM-2000 LUM-2200 LUM-2400 LUM-2400 LUM-2600
Design speed pcs/min 100/ 150/ 200
Economic speed pcs/min 70-80/ 100-130/ 150-160
Max.feeding size mm 950×2000 950×2200 950×2400 1300×2400 1300×2600
Min.size of paperboard

mm



260×500

260×500



260×500



260×500

260×500



Min. space of slotting



Obverse knife mm 160×160×160×160 160×160×160×160
Reverse knife mm 280×80×280×80 280×80×280×80
Max.depth of slot mm 240

240



240



300 300
Skip feeding size mm 1100×2000 1100×2200

1100×2400



1500×2400



1500×2600



Max.printing area mm²

950×1800



950×2000



950×2200



1250×2200



1250×2400



Plate Thickness mm 7.2 7.2 7.2 7.2 7.2
Product Pictures

LUM-B Flexo Printing Slotter Die Cutter Machine(Lead Edge Feeding Type)






Printing unit:





Best price corrugated sheet carton box 2 3 4 color flexo printing slotter machine



Best price corrugated sheet carton box 2 3 4 color flexo printing slotter machine



Packaging & Shipping

Best price corrugated sheet carton box 2 3 4 color flexo printing slotter machine

Company Information

Hebei Lincheng Packaging Machinery Manufacturing Co., Ltd was built in 1997 and high quality enterprise,authorized by Hebei Province Quality and Technical Supervision Bureau,ISO9001 international quality management system certificate and European CE certificate.Our company also hold People's Republic of China Customs Import and Export Right and Packaging Union Vice Chairman Units Honor.

Our company specializes in manufacturing 3-ply,5-ply,7-ply corrugated paperboard production line and carton equipment R&D,manufacturing, and oversea's sales.It covers an area of nearly 20,000 square meters,has a first-class R&D team,technical engineers,excellent management talents and domestic and foreign marketing team.Our products mainly export to America,Russia,Turkey,Korea,Egypt,India,Pakistan,Vietnam,Mexico,Saudi Arabia,the United Arab Emirates,Samoa,South Africa and other 30 countries,etc.We have set our own branch in overseas market.Also,we obtain good appraisement and high appreciation at home and abroad.

Best price corrugated sheet carton box 2 3 4 color flexo printing slotter machineBest price corrugated sheet carton box 2 3 4 color flexo printing slotter machine

FAQ

1. Q: Are you a factory or trading company?

A: We are manufacturer.

2. Q: Where is your company located? How can I visit there?
A: Our company is located in Dongguang County,Cangzhou City,Hebei Province. We are near from Beijing/Tianjin city, only need 2/4 hours,We can arrange car to pick up from airport or hotel

3. Q: Do you have any working machine for us to visit?

A: Yes,We have running machine near our factory also in our city, we can arrange visiting

4. Q: How is the warranty of the machine?

A: Our machines have ONE YEAR WARRANTY. And the engineers available for overseas service.

5. Q:Is it safe on the payment for me as we are the first cooperation?
A: We can do the trade assurance, which will guarantee your products receiving, we also accept other safe payment way as you want.
